R U a Mac?

Notices and warnings

Suggested starting requirements

Reference hardware: Lenovo ThinkCentre M83

The documented reference build used a Lenovo ThinkCentre M83 with:

Lenovo reference: ThinkCentre M83 specification sheet. Check the exact chassis and motherboard revision before applying model-specific advice; the linked PDF is labeled Tower, while the reference system was described as SFF.

What was completed on the reference build

The following describes the observed outcome of the project, rather than claiming that every intermediate command or BIOS setting was recorded.

1. A Windows 11 installation was retained on the separate 1 TB Seagate disk.
2. A 250 GB Samsung SATA SSD was used as the macOS target.
3. macOS Big Sur 11.7.10 was installed and successfully booted on the Lenovo ThinkCentre M83.
4. An OpenCore 1.0.8 EFI initially booted from a 32 GB USB drive.
5. The working USB EFI folder was copied to the Samsung SSD's EFI system partition from Windows 11 using PowerShell.
6. The computer subsequently booted macOS without requiring the USB drive.
7. EFI backups and test variants were kept separately during later experimentation.

Getting started

1. Inventory the hardware

Before downloading or writing anything, record:

• Exact PC model, chassis, motherboard and firmware version.
• CPU model and generation.
• Integrated and discrete GPU models.
• Storage controller and disk model numbers.
• USB controllers and available ports.
• Audio controller, Ethernet controller and other peripherals required for the build.
• Current Windows boot mode (UEFI or Legacy/CSM).

On Windows, useful built-in tools include System Information (msinfo32), Device Manager, Disk Management, and PowerShell:

Get-CimInstance Win32_Processor | Select-Object Name
Get-CimInstance Win32_VideoController | Select-Object Name
Get-PhysicalDisk | Select-Object FriendlyName, MediaType, Size
Get-Disk | Select-Object Number, FriendlyName, Size, PartitionStyle

2. Select a compatible macOS release

Use the Dortania hardware limitations and Dortania installation guide to check CPU and GPU support. For the documented M83 build, the working target was Big Sur 11.7.10.

3. Obtain installation media and OpenCore

Use verified, preferably official sources:

• Dortania OpenCore Install Guide
• OpenCorePkg releases
• Apple: download and install macOS
• ProperTree
• GenSMBIOS

The original project draft referenced a third-party Monterey .raw image, a Woods Studio Simplify archive, and a long GitHub release-asset URL. These are not verified or recommended here. GitHub release-asset URLs containing expiring signed query parameters should be replaced with stable release-page links.

4. Prepare the installer USB

1. Back up the USB drive: it will be erased.
2. Obtain a suitable macOS installer using the procedure appropriate to the chosen release.
3. Create the installation medium following Dortania's Windows instructions.
4. Prepare the USB's EFI system partition with the correct OpenCore files and machine-specific configuration.
5. Verify that EFI/BOOT/BOOTx64.efi and EFI/OC/OpenCore.efi are present, along with the configured drivers, ACPI files and kexts.
6. Keep a complete copy of the USB EFI folder outside the USB before first boot.

5. Configure OpenCore for the exact machine

A typical OpenCore folder has this layout:

EFI/
├── BOOT/
│   └── BOOTx64.efi
└── OC/
    ├── OpenCore.efi
    ├── ACPI/
    ├── Drivers/
    ├── Kexts/
    ├── Resources/
    ├── Tools/
    └── config.plist

config.plist controls the boot environment. Its entries must agree with the actual files under ACPI, Drivers and Kexts.

The reference EFI variants contained components such as Lilu, VirtualSMC, WhateverGreen, AppleALC, SMCProcessor, SMCSuperIO, USBToolBox, UTBDefault, and IntelMausi. Some variants also contained CtlnaAHCIPort. Presence in a ZIP does not prove that a component was enabled, necessary, or working; consult the actual configuration and hardware before reusing it.

Recommended configuration checks:

• Use the Sample.plist that matches the exact OpenCore version.
• Apply only ACPI tables appropriate to the machine.
• Include the drivers actually required by the firmware and filesystem setup.
• Check kext dependencies and load order; for example, dependent plugins should not precede their parent kexts.
• Configure platform information and SMBIOS for the chosen macOS version and hardware.
• Generate unique platform identifiers; do not publish real serial numbers or other machine-specific identifiers in a public repository.
• Validate the completed configuration using the matching ocvalidate executable.
• Save a known-good EFI copy before every change.

6. Check firmware settings

The following are items to investigate, not verified settings from the reference installation:

• Boot mode: UEFI, not an accidental Legacy-only configuration.
• SATA controller mode: normally AHCI when appropriate to the storage configuration.
• Secure Boot and other firmware security features: follow the current OpenCore guidance for the specific system.
• Fast Boot and CSM: adjust only if the installation procedure requires it.
• VT-d, CFG Lock and related options: inspect the motherboard's capabilities and the selected OpenCore quirks before changing them.
• Boot priority: ensure the intended USB or SSD EFI can be selected from the firmware boot menu.

Record original firmware settings before changing anything. Firmware option names differ between models and revisions.

7. Install macOS to the intended disk

1. Boot the prepared installer through OpenCore.
2. Open Disk Utility and enable View → Show All Devices.
3. Identify the target Samsung SSD by model and capacity, not merely by a volume name.
4. Erase only the intended target drive, using a GUID partition map and the filesystem recommended for the chosen macOS installer (normally APFS for Big Sur).
5. Start installation and allow the expected restarts.
6. At each restart, select the appropriate installer or macOS entry through OpenCore until Setup Assistant appears.
7. Complete initial setup, then verify macOS version and the target disk.

8. Boot successfully from USB first

Before migrating the bootloader, confirm that:

• The installer has finished and the macOS desktop is reachable.
• The system can restart and boot again using the USB OpenCore installation.
• The internal macOS SSD is recognized and stable.
• Basic graphics, keyboard, mouse, audio and storage behavior are checked.
• A backup of the exact working USB EFI exists on another drive.

Do not treat a single successful boot as proof that sleep, power management, USB mapping, and all peripherals are fully configured.

Moving OpenCore from USB to the macOS SSD

This migration was successfully completed on the reference build using Windows 11. It removes the requirement to leave the USB plugged in for ordinary macOS boots.

9. Understand the EFI system partition

On a GPT disk, the EFI System Partition (ESP) is a small FAT32 partition used for UEFI boot files. It is distinct from the macOS APFS data/system volumes.

The relevant destination is the Samsung SSD's ESP, not the Seagate Windows disk's ESP.

10. Back up both the working EFI and Windows boot configuration

From Windows:

1. Copy the complete known-working USB EFI folder to a safe location.
2. Export or copy the current SSD EFI folder if one already exists.
3. Save these backups somewhere other than the EFI partition being edited.
4. Confirm Windows can still boot independently, or prepare suitable Windows recovery media.

Suggested backup names:

Backups/
├── EFI-USB-known-good/
├── EFI-SSD-before-migration/
└── EFI-SSD-after-migration/

11. Identify and mount the Samsung SSD's ESP in Windows

Use an Administrator PowerShell or Windows Terminal session:

Get-Disk | Select-Object Number, FriendlyName, Size, PartitionStyle
Get-Partition | Select-Object DiskNumber, PartitionNumber, DriveLetter, Type, Size

Identify the Samsung SSD using its actual current disk number. The ESP is usually a small system partition, but do not rely on size alone.

For a partition that has been positively identified, Windows can assign a temporary drive letter:

# EXAMPLE ONLY — replace these values after checking Get-Partition.
Get-Partition -DiskNumber <SAMSUNG_DISK_NUMBER> -PartitionNumber <EFI_PARTITION_NUMBER> |
    Add-PartitionAccessPath -AccessPath 'S:\'

12. Copy the working EFI to the SSD

After mounting and checking the destination:

# Replace the source with the actual location of the KNOWN-WORKING EFI.
# The source directory must itself contain BOOT and OC subfolders.
Copy-Item -Path 'C:\EFI-USB-known-good' -Destination 'C:\EFI-Backup' -Recurse -Force

# Example: copy the BOOT and OC folders into the mounted ESP's EFI directory.
New-Item -ItemType Directory -Path 'S:\EFI' -Force | Out-Null
Copy-Item -Path 'C:\EFI-USB-known-good\*' -Destination 'S:\EFI' -Recurse -Force

Important: These commands are illustrative and assume the source folder contains BOOT and OC. They do not delete stale destination files. If the SSD already has an EFI folder, inspect and back it up first rather than merging configurations blindly.

Check the resulting structure:

S:\EFI\BOOT\BOOTx64.efi
S:\EFI\OC\OpenCore.efi
S:\EFI\OC\config.plist

Compare the copied files with the known-working source. A file-by-file or cryptographic-hash comparison is preferable to assuming that a successful copy operation means everything is correct.

13. Boot from the SSD

1. Shut down Windows.
2. Remove the installation USB.
3. Open the PC's firmware boot menu.
4. Select the Samsung SSD's UEFI/OpenCore entry, if available.
5. Confirm that OpenCore starts and macOS boots.
6. Restart once more to check repeatability.

If no SSD boot entry appears, inspect the ESP layout and firmware boot entries. Do not erase or replace the Windows Boot Manager to make OpenCore appear.

Reference result: The M83 successfully booted Big Sur without the USB after the working EFI was copied to the Samsung SSD.

Windows and macOS dual-boot considerations

Because Windows and macOS occupy separate physical drives, either OS can often be selected from the motherboard's firmware boot menu. OpenCore may also display Windows, depending on configuration.

Recommended safeguards:

• Keep the Windows drive's own EFI and Windows Boot Manager intact.
• Do not run generic “repair EFI” scripts without inspecting which physical disk they modify.
• Avoid deleting firmware boot entries merely to change the default OS.
• Document which disk contains each EFI partition.
• After major changes, test both operating systems.

Troubleshooting

OpenCore does not appear

Check whether the firmware is using UEFI boot mode, whether the correct physical drive was selected, and whether EFI/BOOT/BOOTx64.efi exists. If the USB boots but the SSD does not, compare the two ESP folder structures and firmware boot entries.

OpenCore appears, but macOS does not boot

Return to the last known-good EFI. Check the latest changed kexts, drivers, ACPI entries, boot arguments, and config.plist syntax. Enable OpenCore logging only as needed and avoid publishing logs containing unique platform identifiers.

Boot stops during installation

Confirm the installer is complete, the target disk is prepared correctly, and the correct installer-stage entry is selected after each restart. A changing entry name across restarts can be normal.

Black screen or unusable graphics

Check the GPU against the target macOS release and review framebuffer, connector and graphics-related configuration. Do not assume that a display signal proves hardware acceleration is active.

Keyboard or mouse stops working

Inspect USB port mapping, USB controller behavior and the relevant input drivers. Keep an alternative input device or port available during testing.

SSD is missing from Disk Utility

Check physical cabling, firmware detection, controller mode, and storage-controller compatibility. Do not format the Windows drive simply because it is the only visible disk.

Windows no longer appears as a boot option

Use the firmware boot menu to look for Windows Boot Manager on the Seagate drive. Restore the known-good EFI if a recent change caused the problem. Avoid rewriting the Windows disk until its actual boot state has been assessed.

Post-install checklist

A working desktop is the beginning of validation, not the end:

• [ ] macOS boots from the internal SSD without the installation USB.
• [ ] Windows still boots from its separate disk.
• [ ] Both OS drives are identified correctly.
• [ ] The macOS version and bootloader version are recorded.
• [ ] Graphics acceleration and display outputs are verified.
• [ ] Audio input and output are tested.
• [ ] All intended USB ports are mapped and tested at appropriate speeds.
• [ ] Sleep, wake, restart and shutdown are tested.
• [ ] CPU power management and temperatures are checked.
• [ ] System clock and time-zone behavior are checked across both operating systems.
• [ ] The EFI configuration passes the matching ocvalidate check.
• [ ] A known-good EFI backup and recovery procedure are stored safely.
• [ ] Machine-specific identifiers and logs are removed from anything published publicly.

Beginner walkthrough: decisions before clicking anything

A. Identify the PC in Windows

Open Start → System Information (msinfo32). Record System Model, BIOS Version/Date, and BIOS Mode. BIOS Mode should report UEFI for the UEFI workflow described here. Open Device Manager to identify display and storage controllers; use Task Manager → Performance to cross-check memory and disk capacity.

Run these commands in PowerShell (they only read information):

Get-CimInstance Win32_Processor | Select-Object Name
Get-CimInstance Win32_BaseBoard | Select-Object Manufacturer,Product
Get-CimInstance Win32_VideoController | Select-Object Name,DriverVersion
Get-PhysicalDisk | Select-Object FriendlyName,MediaType,Size
Get-Disk | Format-Table Number,FriendlyName,PartitionStyle,Size

Write the results into a worksheet without sharing device serial numbers publicly:

B. Choose the right installation path

C. What the installer USB actually contains

An OpenCore bootloader alone does not install macOS. A successful workflow needs both a suitable macOS installer/recovery environment and a compatible OpenCore EFI. On Windows, the official Dortania guide documents a recovery-based installer workflow, which may require network access during installation. A full offline installer is a separate workflow and should not be assumed from a 16 GB USB capacity alone.

OpenCore files explained — no guessing

Exact configuration verification

1. Extract the OpenCore release package for the chosen version.
2. Begin with its matching sample configuration, not an unrelated internet EFI.
3. Populate ACPI, kext and driver folders for the actual hardware.
4. Use ProperTree to snapshot the OC directory and inspect all resulting entries.
5. Confirm Lilu.kext appears before kexts that depend on it, and VirtualSMC.kext before its plugins.
6. Validate using Utilities/ocvalidate from the same OpenCore release.
7. Inspect and fix every reported error. A successful validation checks configuration structure; it does not prove hardware compatibility.
8. Store the exact working configuration in a private backup before testing a change.

Windows PowerShell example (adjust the two paths to the extracted OpenCore package and EFI):

$OpenCoreRoot = 'C:\OpenCore-1.0.8-RELEASE'
$Config = 'C:\EFI-Staging\EFI\OC\config.plist'
$Validator = Join-Path $OpenCoreRoot 'Utilities\ocvalidate\ocvalidate.exe'
if (!(Test-Path $Validator)) { throw "ocvalidate not found: $Validator" }
if (!(Test-Path $Config)) { throw "config.plist not found: $Config" }
& $Validator $Config
if ($LASTEXITCODE -ne 0) { throw 'OpenCore validation failed; do not deploy.' }

SSD EFI migration — extra-safe Windows procedure

The following is a recommended repeatable method, not a verbatim record of the reference machine's earlier PowerShell commands.

1. Identify the disks without writing to them

In Administrator PowerShell:

Get-Disk | Format-Table Number,FriendlyName,PartitionStyle,Size
Get-Partition | Format-Table DiskNumber,PartitionNumber,DriveLetter,Type,Size

Locate the Samsung 250 GB SSD by name and size. Note its disk number. Locate its EFI System Partition using partition type and disk association; do not guess from partition number or drive letter. Verify that the Seagate 1 TB Windows disk is a different physical disk.

2. Mount only the verified Samsung EFI partition

# REPLACE both values with numbers verified above.
$MacDiskNumber = 1
$MacEspPartitionNumber = 1

$disk = Get-Disk -Number $MacDiskNumber
$part = Get-Partition -DiskNumber $MacDiskNumber -PartitionNumber $MacEspPartitionNumber
$disk | Format-List Number,FriendlyName,Size
$part | Format-List DiskNumber,PartitionNumber,GptType,Type,Size

Do not run the next command unless the displayed disk and partition are correct. The numeric values above are placeholders, not the reference machine's confirmed numbers.

# S: must be free. This adds a drive-letter access path; it does not format the ESP.
Add-PartitionAccessPath -DiskNumber $MacDiskNumber `
  -PartitionNumber $MacEspPartitionNumber -AccessPath 'S:\'

If Windows refuses access, stop and inspect the error. Do not run format, clean, convert, or delete partition to solve a mount problem.

3. Back up before replacing anything

New-Item -ItemType Directory -Path 'C:\Hackintosh-Backups' -Force | Out-Null
Copy-Item 'S:\EFI' 'C:\Hackintosh-Backups\EFI-before-change' -Recurse -Force
Test-Path 'C:\Hackintosh-Backups\EFI-before-change\OC\config.plist'

The final command should return True when the existing SSD EFI has OpenCore's configuration. If it returns False, inspect the source folder and backup; do not continue. If the SSD EFI has a different layout, preserve it exactly and investigate before changing anything.

4. Stage and inspect the replacement first

Extract the new EFI ZIP into C:\EFI-Staging and check:

$Staged = 'C:\EFI-Staging\EFI'
@('BOOT\BOOTx64.efi','OC\OpenCore.efi','OC\config.plist') |
  ForEach-Object { '{0}: {1}' -f $_, (Test-Path (Join-Path $Staged $_)) }

All three checks must be True. Run ocvalidate against the staged configuration before deployment. Keep the original backup outside the ESP. If the ESP contains unrelated boot folders, preserve them; never delete the Windows boot folder from the Windows disk.

5. Deploy and verify the copy

Only after validation and backup, and only if the target S: is the Samsung ESP:

# Back up the existing folder first (previous step), then replace only the
# Samsung ESP's OpenCore-related files, preserving any unrelated boot files.
Copy-Item 'C:\EFI-Staging\EFI\BOOT\*' 'S:\EFI\BOOT' -Recurse -Force
Copy-Item 'C:\EFI-Staging\EFI\OC\*' 'S:\EFI\OC' -Recurse -Force

@('BOOT\BOOTx64.efi','OC\OpenCore.efi','OC\config.plist') |
  ForEach-Object { '{0}: {1}' -f $_, (Test-Path (Join-Path 'S:\EFI' $_)) }

6. Unmount and boot-test

Remove-PartitionAccessPath -DiskNumber $MacDiskNumber `
  -PartitionNumber $MacEspPartitionNumber -AccessPath 'S:\'

Restart, use the motherboard's one-time boot menu, select the SSD's UEFI entry, and verify two successful macOS boots. Then test direct Windows Boot Manager. If the system fails, use the separate recovery path to restore EFI-before-change rather than improvising further edits on the only bootable EFI.

Troubleshooting by symptom

Collect useful evidence before asking for help

Provide model, CPU, GPU, macOS release, OpenCore release, exact error text, and the stage at which boot stops. Capture a photo of the last visible verbose lines rather than only saying “it doesn't work.” Never publicly post an unredacted config.plist containing SMBIOS serials, UUIDs, MLB values or ROM data. Share a sanitized config and a list of enabled kexts instead.

Post-install verification — commands and expected results

After the first successful boot, use macOS Terminal:

sw_vers                    # ProductVersion and BuildVersion
system_profiler SPHardwareDataType
system_profiler SPDisplaysDataType
system_profiler SPStorageDataType

Then test: keyboard and mouse on every needed USB port, graphics acceleration, sound output, sleep/wake, restart/shutdown, correct system time, and a cold boot without the installer USB. Record each as PASS, FAIL, or NOT TESTED. A successful desktop boot is not proof that all of these work.

R U a Mac? tool design — make the easiest path the safest path

Proposed beginner wizard

1. Welcome / risks: Explain unsupported hardware, data loss, licensing and backup requirements in plain language.
2. Scan hardware: Read CPU generation, GPU device ID, RAM, firmware mode, disk models and partition maps without making changes.
3. Compatibility report: Show Supported, Needs manual verification, or Unsupported for the selected macOS release, with links to evidence. Never promise a working install from CPU model alone.
4. Choose target: Display disks by brand + capacity + Windows/macOS labels. Require explicit confirmation of the intended erase target.
5. Select installer type: Online recovery vs full offline media, with internet/storage requirements and source verification.
6. Build EFI: Select version-matched OpenCore files and hardware-appropriate kexts/ACPI. Generate unique SMBIOS data locally, never in public logs.
7. Validate: Run matching ocvalidate, verify every referenced file, detect missing dependencies and refuse deployment on errors.
8. Write USB: Display the exact removable device and require a final confirmation before erasing it. Verify written content afterward.
9. Guided BIOS screen: Show model-specific steps only when verified; otherwise show a checklist and link to manufacturer documentation.
10. Install companion guide: Provide screenshots and restart-by-restart instructions. Never automate destructive APFS formatting without unambiguous confirmation.
11. Migrate EFI: Identify the target disk's ESP, back it up, stage changes, validate, copy and verify. Preserve Windows boot entries.
12. Health check: Produce a redacted diagnostics bundle, checklist, and rollback instructions.

Safety requirements for the app

• Default to read-only scanning. Separate scanning from writing.
• Never choose a target disk solely from its disk number; Windows disk numbering can change.
• Detect BitLocker/device encryption and warn about recovery-key implications before firmware or boot changes.
• Make a backup of every modified ESP before applying changes, and confirm the backup is readable.
• Never write a sample SMBIOS identity unchanged to multiple machines.
• Keep an audit log of file operations without personal identifiers.
• Support dry-run mode that shows exactly which files would be added, replaced or deleted.
• Provide a tested rollback route before the first write.
• Make unsupported hardware and unverified patches clearly visible; do not hide them behind a “Fix All” button.

Example repository content to add

docs/
  00-before-you-start.md
  01-hardware-check.md
  02-macos-compatibility.md
  03-create-installer.md
  04-build-opencore-efi.md
  05-bios-and-first-boot.md
  06-install-macos.md
  07-migrate-efi-from-windows.md
  08-post-install-tests.md
  09-recovery-and-rollback.md
  troubleshooting/
  hardware/
    lenovo-thinkcentre-m83.md
examples/
  hardware-report.REDACTED.json
  install-checklist.md

Roadmap: what R U a Mac? still needs

These are proposed product features, not features confirmed to exist in the current Woods Studio tool.

Phase 1 — Hardware detection and compatibility

• [ ] Collect hardware information from Windows without requiring users to type device IDs manually.
• [ ] Detect CPU generation, GPU, firmware boot mode, storage controllers and USB controllers.
• [ ] Provide a per-component compatibility report for each supported macOS release.
• [ ] Explain why a release is recommended, unsupported, or requires additional work.
• [ ] Distinguish verified compatibility from community reports and experimental configurations.

Phase 2 — Installer creation

• [ ] Use trustworthy installer acquisition methods with checksum verification.
• [ ] Warn before erasing a USB or target disk and display its model and capacity.
• [ ] Create online-recovery or full offline media where supported.
• [ ] Detect and validate GPT, FAT32 ESP and installation-media layout.
• [ ] Provide a clear progress indicator, detailed log and recovery guidance.

Phase 3 — OpenCore configuration

• [ ] Download pinned OpenCore releases from stable release pages.
• [ ] Select required drivers, ACPI files and kexts based on detected hardware.
• [ ] Resolve dependencies and correct load order automatically.
• [ ] Generate and validate config.plist against the matching OpenCore schema.
• [ ] Generate unique platform identifiers locally and keep them private.
• [ ] Produce a machine-readable compatibility report and an editable EFI manifest.
• [ ] Refuse to overwrite a working EFI without a verified backup.

Phase 4 — Guided installation and SSD migration

• [ ] Explain firmware options with model-specific warnings.
• [ ] Walk through Disk Utility selection with explicit disk-identity checks.
• [ ] Detect when macOS has completed setup.
• [ ] Provide a Windows-based copy EFI to SSD workflow.
• [ ] Verify copied files and preserve existing Windows boot entries.
• [ ] Offer a rollback option for every bootloader change.

Phase 5 — Validation and support

• [ ] Run a post-install health checklist.
• [ ] Capture sanitized diagnostic logs with explicit consent.
• [ ] Provide targeted troubleshooting based on the last boot stage.
• [ ] Track which hardware/macOS combinations have been tested successfully.
• [ ] Publish reproducible test results, limitations and known issues.
• [ ] Document the upgrade path for OpenCore and individual kexts without implying automatic compatibility.

Repository layout (proposed)

R-U-a-Mac/
├── README.md
├── LICENSE
├── SECURITY.md
├── CONTRIBUTING.md
├── docs/
│   ├── hardware-compatibility.md
│   ├── installation-windows.md
│   ├── firmware-settings.md
│   ├── opencore-configuration.md
│   ├── migrate-efi-to-ssd.md
│   ├── dual-boot.md
│   ├── troubleshooting.md
│   └── tested-hardware/
│       └── lenovo-thinkcentre-m83.md
├── manifests/
│   ├── releases.json
│   └── compatibility.json
├── scripts/
│   └── windows/
└── tests/

Reference links

• Woods Studio Labs
• R U a Mac? project website
• Dortania OpenCore Install Guide
• OpenCorePkg releases
• OpenCore configuration documentation
• Apple macOS download guidance
• ProperTree
• GenSMBIOS
• Lenovo ThinkCentre M83 specification sheet

Project status: Experimental documentation and tooling under development. The reference M83 reached a working Big Sur installation and SSD-based OpenCore boot, but the end-to-end automated workflow has not yet been validated.
